T1M-04-GF-DH

Name: Samtec T1M-04-GF-DH
Brand: Samtec
SKU: 200-T1M04GFDH
Price: 20.3 HKD
Availability: InStock

影像僅供參考
請參閱產品規格

Mouser 編號：

200-T1M04GFDH

製造商編號：

T1M-04-GF-DH

製造商：

Samtec

說明：

集管和線殼 Discrete Wire Terminal Strip

規格書:

T1M-04-GF-DH 規格書 (PDF)

ECAD模型:

下載免費的庫載入器，為ECAD工具轉換此文件。瞭解更多關於 ECAD 型號的資訊。

更多資訊

瞭解更多關於Samtec T1M-04-GF-DH的資訊

庫存量: 627

庫存：: 627 可立即送貨

發生意外錯誤了。請稍後再試。
工廠前置作業時間：: 52 週工廠預計生產時間數量大於所顯示的數量。

輸入數量：

最少： 1 多個： 1

單價:

HK$-.--

總價:

HK$-.--

估計關稅:

Pricing (HKD)

數量	單價	總價
	HK$20.30	HK$20.30
	HK$19.07	HK$476.75
	HK$17.92	HK$896.00
	HK$16.93	HK$1,693.00
完整捲（訂購多個275）
	HK$16.93	HK$4,655.75
	HK$15.78	HK$13,018.50
	HK$14.30	HK$35,392.50
	HK$12.49	HK$61,825.50
9,900	報價

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

商品屬性	屬性值	選擇屬性
製造商:	Samtec
產品類型:	集管和線殼
RoHS:
產品:	Headers
類型:	Discrete Wire Terminal Strip
定位數:	8 Position
間距:	1 mm (0.039 in)
排數:	2 Row
安裝風格:	SMD/SMT
終端類型:	Solder
裝配角:	Right Angle
聯繫人性別:	Pin (Male)
觸點电镀:	Gold
系列:	T1M
應用:	Board-to-Cable
線規:	28 AWG
最低工作溫度:	- 55 C
最高工作溫度:	+ 125 C
封裝:	Reel
封裝:	Cut Tape
品牌:	Samtec
觸點材料:	Phosphor Bronze
組裝國家:	Not Available
擴散國:	Not Available
原產國:	CR
额定电流:	3.3 A
易燃性等級:	UL 94 V-0
外殼顏色:	Natural
外殼材料:	Liquid Crystal Polymer (LCP)
絕緣電阻:	1 GOhms
產品類型:	Headers & Wire Housings
原廠包裝數量:	275
子類別:	Headers & Wire Housings
額定電壓:	250 VAC/353 VDC

找到產品:

若要顯示類似商品，請選取至少一個核選方塊

至少選中以上一個核取方塊以顯示在此類別中類似的產品。

所選屬性: 0

篩選文檔:

Specification Sheets

Technical Resources

Test Report (PDF)

CNHTS:: 8536901100
CAHTS:: 8536690020
USHTS:: 8536694040
JPHTS:: 853669000
KRHTS:: 8536691000
TARIC:: 8536693000
MXHTS:: 8536699999
BRHTS:: 85366990
ECCN:: EAR99

5G Solutions

Samtec 5G Solutions support the ultra-high frequencies and high data rates that emerging 5G technologies demand. As this 5G network quickly gains momentum, new systems, devices, and equipment are needed for technologies such as mmWave, Massive MIMO, beamforming, and full-duplex (FDX). Samtec 5G Solutions feature high-performance products for four applications: Test and Development Systems, Remote Radio and Active Antennas, Network Equipment, and Automotive and Transportation.

1mm Discrete Wire System

Samtec 1mm Discrete Wire System is a space-saving discrete wire system with crimp-style dual leaf contacts for a reliable wire-to-board connection. This Samtec 1mm-pitch wire system offers single-row (2-20 contacts) and double-row (4-40 contacts) versions and vertical and right-angle PCB connectors. These interconnects are available as components or complete assemblies.

T1M 1mm Discrete Wire Terminal Strips

Samtec T1M 1mm Discrete Wire Terminal Strips are built with phosphor bronze contact material and liquid crystal polymer (LCP) housing material. These discrete wire components are designed with 3.3A current rating, 250V voltage rating, and operate at a temperature range of -40°C to +125°C. The 1mm discrete wire terminal strips are available in single- and double-row variants with SMD/SMT termination styles.
